Product
Model HP ProLiant DL380 Generation 7 (G7)
P/N 633408-371
Form Factor Rack 2U
Processor
Processor Quad-Core Intel Xeon Processor E5606 (2.13 GHz, 4MB L3 Cache, 80 Watts, DDR3-800)
Speed supported E5606 2.13 GHz
Cache size 4MB L3 Cache
Data bus speed DDR3-800
Upgradeability Upgradeable to two processors
Chipset Intel® 5520 chipset
Memory
Type DDR3 Registered (RDIMM) and Unbuffered (UDIMM)
Installed Size 4GB (2 x 2GB) PC3-10600R (DDR3-1333) Registered DIMMs
Maximum (RDIMM) 192GB (12 x 16GB) for Registered Memory configurations
Maximum (UDIMM) 48GB (12 x 2GB) for Unbuffered Memory configurations
Network Controller
Adapter Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports total) with TCP/IP Offload Engine, including support for Accelerated iSCSI
Expansion Slots #
PCIe Gen2 x16 x 1
PCIe Gen2 x8 x 2
PCIe Gen2 x8 x 3
Storage Controller
Performance Model HP Smart Array P410i/Zero Memory Controller (RAID 0/1/1+0)
Support Available upgrades: 1G FBWC, 512MB FBWC, 256MB, 512MB with BBWC, Battery kit upgrade (for the 256MB cache), and Smart Array Advanced Pack (SAAP)
Storage
Diskette Drive None
Optical Drive DVD ROM
Hard Drive 146GB Hot-Plug SAS 10K 2,5"
Maximum Internal Storage
Hot Plug SFF SAS 9.6TB (16 x 600GB (with optional SFF drive cage))
Hot Plug LFF SAS 12.0TB (6 x 2TB (with optional LFF drive cage))
Interfaces
Serial 1
Network RJ-45 4
Graphics 2 (1 front, 1 bac
